Key Features

• W, KW, HP, VA, KVA, VAR, KVAR
• PF, Phase Angle (Φ)
• Energy (WH, KWH)
• Balanced 3Φ Power Quality
• Balanced 3Φ Sequence
• Programmable CT Ratio (1 to 250)
• Dual Displays (W + PF, VA + KVAR…)
• Active power in HP
• Resistance and Continuity with Beeper

• True RMS value (V and A) at 0.5% basic accuracy
• 1500 A AC
• Harmonics Analysis (V and A) to the 99th Order in % and in magnitude
• Better Understaning of High Frequency Harmonic Analysis (up to 5/6/KHz)
• Non-interrupted Harmonic Analysis
• Analysis of Total Harmonic Distortion(%THD-F)
• Analysis of Crest Factor (C.F.)
• Fast Peak Function (33μs for 60Hz and 39μs for 50Hz)
• Max, Min & Data Hold Function
